1756-OW16I Allen Bradley: Powerhouse Discrete Output Module
Key Features:
- Isolated Outputs: Sixteen (16) individually isolated channels ensure reliable operation even in challenging environments.
- Versatile Voltage Range: Compatible with a wide range of operating voltages from 5-125VDC and 10-240VAC.
- High Output Current: Delivers up to 1.5 A @ 120VAC, 50/60 Hz, making it suitable for demanding loads.
- Rapid Signal Transition: Experience minimal delay with a maximum output signal delay of 10 ms for both ON to OFF and OFF to ON transitions.
Technical Specifications:
- Module Type: Digital DC Sourcing Output
- Series: ControlLogix
- Part Number: 1756-OW16I
- Brand: Allen-Bradley
- Outputs: 16-Point Individually Isolated
- Operating Voltage: 10-265V AC, 5-150V DC
- Output Current: 2, 0.5, 0.25 Amps
- Maximum Output Delay Time: 10 milliseconds
- Contact Output: 13 N.O.
- Power Dissipation (Max): 4.5 Watts at 60 Celsius
- Backplane Current: 150 milliamps at 5 Volts and 24 Volts
- Removable Terminal Block: 1756-TBCH, 1756-TBS6H
